TURN SIGNAL LAMPS
SIG
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
32
1.59”
4.32”
1.59”
4.32”
5.5”
0.07”
1.63”
4.49”
LED
Super 44
®
Rear Turn
Materials
• Polycarbonate or acrylic lens
• Polycarbonate or ABS housing
• PVC grommet
• 16 gauge wire
Light Source
• 6 Light emitting diodes (LEDs)
• 12v designed at 0.249A - 0.31A
• 24v designed at 0.080A -
0.125A
Kit Components:
44107Y:
1 - 44285Y lamp and gray flange
1 - 94789 Fit N Forget stop/turn
adapter
44108Y:
1 - 44281Y lamp
1 - 40700 grommet
1 - 94789 fit forget stop/turn
adapter
44109Y:
1 - 44289Y lamp and black flange
1 - 94789 fit forget stop/turn
adapter
44113Y:
1 - 44283Y 24v lamp
1 - 94789 fit forget stop/turn
adapter
1 - 40700 grommet
• Less current draw, resulting in increased battery & alternator life while
allowing more power for other vehicle requirements
• Faster illumination offers significant safety benefit for following drivers
to react quicker, resulting in an average distance of 3 for every 10 mph
• LEDs have no filament, therefore are impervious to shock and vibration
• Flange mounts are permanently affixed to lamp
• Mounts only to rear of vehicle
• Designed to comply with FMVSS 108
• Limited lifetime warranty
44280Y Diamond Shell, lamp, yellow
44281Y 12 V, lamp, yellow
44283Y 24 V, lamp, yellow
44285Y Gray flange, lamp, yellow
44286Y Black flange, 24 V, lamp, yellow
44287Y Diamond Shell, gray flange, lamp, yellow
44289Y Black flange, lamp, yellow
5.5”
0.07”
1.63”
4.49”
