TURN SIGNAL LAMPS
SIG
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
34
LED
Super 44
®
Rear Turn
42 Diode Pattern
Material:
• Polycarbonate or acrylic lens,
housing & flange
• PVC grommet
• 16 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• 12v designed at 14v, .5 amp
• 24v designed at 28v, .31 amp
Kit Components:
• 44001Y grommet kit
1 - 44201Y lamp
1 - 40700 grommet
1 - 94789 adapter plug
• 44021Y gray flange kit:
1 - 44221Y lamp & flange
1 - 94789 adapter plug
• 44027Y black flange kit:
1 - 44227Y lamp & flange
1 - 94789 adapter plug
• 44018Y grommet kit:
1 - 44273Y lamp
1 - 40700 grommet
1 - 94706 adapter plug
Recommended Accessories:
• Mounting: Pages 259-261
• Plugs: Pages 216-217
FMVSS:
• I6
• Uniquely designed shock-
mount extends lamp life
• Uses standard mounting holes
& accessories
2.11
4.31
• Less current draw, resulting in increased battery & alternator life while allowing
more power for other vehicle requirements
• Faster illumination offers significant safety benefit for following drivers to react
quicker, resulting in an average of 3’ reaction time advantage for every 10 m.p.h.
• LEDs have no filament, therefore are not susceptible to shock & vibration, a
major cause of failure for lamps with incandescent bulbs
LED Gray Flange Kits
44021Y Yellow
LED Black Flange Kits
44027Y Yellow
LED Grommet Kits
44001Y Yellow
44018Y Yellow, 24v
LED Lamps
44201Y Yellow
44881Y Yellow, diamond shell
44273Y Yellow, 24v
4.35
1.74
LED Lamp & Gray Flange
44221Y Yellow
44887Y Yellow, diamond shell
LED Lamp & Black Flange
44227Y Yellow
44888Y Yellow, diamond shell
44276Y Yellow, 24v
LED Lamp & White Flange
44231Y Yellow
1.74
5.50
Super 40
®
Turn Signal
Sealed
Material:
• Polycarbonate lens & housing
• PVC grommet
• 16 gauge wire
Light Source:
• Designed at 13.5v, 2.1 amps,
32cp
Kit Components:
• 40041Y grommet kit:
1 - 40241Y lamp
1 - 40700 grommet
1 - 94992 right angle plug
Recommended Accessories:
• Mounting: Pages 259-261
• Plugs: Pages 213-214
FMVSS:
• I6
40041Y
See Above
40041Y Yellow, grommet kit
40241R Red lamp
40241Y Yellow lamp
