38 / 348
TURN SIGNAL LAMPS
SIG
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
36
60
®
Series Side
Turn & Marker
Sealed
Material:
• Polycarbonate lens & housing
• PVC grommet
• 16 gauge wire
Light Source:
• Dual filament baseless bulb
• 12v bulb designed at 2.1/.49 amp,
32/2 cp
• 24v designed at 28v, .93/.34 amp,
32.6 cp
Kit Components:
60015R/Y grommet kits:
1 - 60215R/Y lamp
1 - 60700 grommet
1 - 94993 right angle plug
Recommended Accessories:
• Mounting: Pages 262-263
• Plugs: Pages 213-215
FMVSS:
• Red: A,PS
• Yellow: A,E,P2
2.16
7.88
3.31
2.16
6.50
2.32
LED
Super 60
®
Side Turn
Signal & Marker
11 Diode Pattern
Material:
• Polycarbonate lens, housing & flange
• ABS flange
• PVC grommet
• 16 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 13.5v, .5 amp (turn),
.05 amp (marker)
Kit Components:
60115Y grommet kits:
1 - 60315Y lamp
1 - 60700 grommet
1 - 94706 adapter plug
60117Y flange kit:
1 - 60317Y lamp & flange
1 - 94706 adapter plug
Recommended Accessories:
• Mounting: Pages 262-263
• Plugs: Pages 213-215
FMVSS:
• E,P2
• U.S. Patent #7055996
• World’s first LED side turn signal to surpass SAE J2039 standards in large
vehicle applications
• Commonly mounted at “mid-point” on trailers or “no zone” areas on tractors
• Faster illumination offers significant safety benefit for following drivers to react
quicker, resulting in an average of 3’ reaction time advantage for every 10 m.p.h.
LED Grommet Kits
60115Y Yellow
LED Yellow Flange Kits
60117Y Yellow
LED Lamps
60315Y Yellow
LED Lamp & Yellow Flange
60317Y Yellow
60317Y
60315Y
6.50
2.50
2.25
See Above
• Features side indicator, marker/clearance & reflector functions
• Narrow width facilitates horizontal mounting
• Red lamp should be used only for rear vehicle applications
• Meets SAE J2039 recommendation for side turn signal
60015R Red, grommet kit
60015Y Yellow, grommet kit
60215R Red lamp
60015Y
60215R
60215Y Yellow lamp
60216Y Yellow lamp & gray flange
60217Y Yellow lamp, 24v
