Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
35
TURN SIGNAL LAMPS
• Hardwired design
• Mount horizontally or vertically• Permanently affixed flange mount version
• Standard connector makes retrofitting a snap
2.11
4.31
See Page 32
40
®
Series Turn & Tail
4” Sealed
Material:
• Polycarbonate lens & housing
• PVC grommet
• 16 gauge wire
Light Source:
• 12v bulb designed at 2.1 amps,
32 cp
Recommended Accessories:
• Mounting: Pages 259-261
• Plugs: Pages 216-217
FMVSS:
• I6
• Uses standard mounting holes and accessories
• Heavy duty shock-mounted bulb
40201Y Yellow lamp
1.42
3.40
5.31
1.43
4.22
6.13
LED 45
®
Series Rear Turn
70 Diode Pattern
Material:
• Polycarbonate lens, housing & flange
• Black PVC grommet
• 18 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• 12v designed at .75 amp
• 24v designed at 28v .7 amp
Kit Components:
45051Y 12v grommet kit:
1 - 45251Y lamp
1 - 45700 grommet
45063Y 24v grommet kit:
1 - 45263Y lamp
1 - 45700 grommet
Recommended Accessories:
• Mounting: Pages 259
FMVSS:
• I6
45051Y Yellow, grommet kit
45063Y Yellow, grommet kit, diamond shell, 24v
45251Y Yellow lamp
45263Y Yellow lamp, diamond shell, 24v
45251Y
3.43
5.31
1.93
.56
See Above
Super 45
®
Turn Signal
Sealed
Material:
• Polycarbonate lens & housing
• PVC grommet
• 16 gauge wire
Light Source:
• Single filament baseless bulb
• Designed at 2.1, 32 cp
Kit Components:
45001 Y grommet kit:
1 - 45201R/Y lamp
1 - 45700 grommet
1 - 94992 plug
Recommended Accessories:
• Mounting: Pages 259
• Plugs: Pages 213-214
FMVSS:
• I6
• Heavy duty bulb for longer life
• Mount horizontally or vertically
45001Y
Yellow, grommet kit
45201R
Red lamp
45201Y
Yellow lamp
45204
Clear back-up lamp w/reflector
45001Y
