70
LED P2 Lamp w/male pin
connection
19250R Red
19250Y Yellow
19251R Red w/clear lens
19251Y Yellow w/clear lens
LED
19
®
Series
PC Rated
Sealed
2-6 Diode Pattern
Material:
• Polycarbonate lens & housing
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 14v, 0.05 amp
• PC rated lamp designed at
14v, 0.05 amp (red), 0.12 amp
(yellow)
Recommended Accessories:
• Mounting: Page 258
• Plugs: Pages 226
FMVSS:
• P2,P3,PC2
3.78
0.83
1.23
3.78
0.83
1.23
3.78
0.83
1.23
3.78
0.83
1.23
• Innovative optic design allows combination lamps to function as two
• Draws less current, allowing more power for other vehicle requirements
• Designed to fit applications requiring minimalspace
• Must be mounted horizontally
• PC rated lamps meet requirements when mounted on a 45˚ angle
• P2 red lamps have 2 diode pattern, PC rated red lamps & standard yellow
lamps have 4 diode pattern, and P2 rated yellow lamps have 6 diode pattern
LED P2 Lamp w/Fit ’N Forget
connection
19350R Red
19350Y Yellow
LED PC Rated Lamp w/male
pin connection
19275R Red
19275Y Yellow
LED PC Rated Lamp w/Fit ’N Forget
connection
19375R Red
19375Y Yellow
3.91
0.51
1.22
• Popular in owner/operator & show trucks
• Standard male pin connection
• 4 diode LED pattern
• Encapsulated electronics
• Not recommended for PC applications
1960 Red lamp
1960A Yellow lamp
1961 Red lamp w/clear lens
1961A Yellow lamp w/clear lens
1961A
1961
1960
1960A
LED
Marker &
Clearance
Sealed
4 Diode Pattern
Material:
• Polycarbonate lens & housing
Light Source:
• Light Emitting diodes (LEDs)
• Designed at 13.5v, 0.05 amp
Recommended Accessories:
• Mounting: Page 258
• Plugs: Pages 226
FMVSS:
• P2
