Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
73
M/C
6.00
0.56
2.03
4.81
6.00
4.81
1.30
2.03
6.00
1.30
2.03 4.81
6.50
2.67
2.01
.65 dia
4.81
See page 72
Super 21
®
Rectangular Sealed
Material:
• Acrylic lens
• ABS housing
• 16 gauge wire
Light Source:
• 12v designed at 14v, 0.33 amp, 2 cp
• 24v designed at 28v, 0.17 amp, 3 cp
Kit Components:
21001R/Y kits:
1 – 21200R/Y or 21205R/Y 24v lamp
1 – 96930 hot wire
21002R/Y kits:
1 – 21201R/Y 12v lamp w/reflector
1 – 96930 hot wire
21506R kits:
1 – 21200R/Y 12v lamp
1 – self piercing plug
21501R/Y kits:
1 – 21203R/Y 12v lamp w/reflector
1 – 21720 extension bracket
1 – 96914 plug
1 – 96915 plug
Recommended Accessories:
• 97034 mounting gasket
• 97036 sealing gasket
• Plugs: Pages 226
FMVSS:
• Reflectorized - A,P2
• P2,PC
• Available with standard or reflectorized lens
• Suitable for PC requirements on a 45˚ angle with additional reflectors
• Version available for ABS requirements
• Optional gaskets available to improve seal between lamp & body
• Kits with extension brackets are a direct replacement for
Utility Trailer #03-5100-0-097/8
21201R
21210Y
Lamp Kits
21001R Red
21001Y Yellow
Reflectorized Kits
21002R Red
21002Y Yellow
Lamp
21200R Red
21200Y Yellow
21205R Red, 24v
21205Y Yellow, 24v
Reflectorized Lamp
21201R Red
21201Y Yellow
Kits w/Extension
Bracket
21501R Red
21501Y Yellow
12v Lamps w/Self
Piercing Plug
21506R Red
“ABS” Logo Lamp
21210Y Yellow
Extension Bracket
21720 White
21721 Black
21722 Black, angle
