74 / 348
M/C
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
72
21275R
21275Y
21251Y
21251R
6.00
1.30
2.03
4.81
6.00
4.81
1.30
2.03
LED
21
®
Series
PC Rated
Sealed
1-8 Diode Pattern
Material:
• Polycarbonate or acrylic lens
& housing
• 16 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• 12v designed at 14v, 0.10 amp
• 24v designed at 28v, 0.05 amp
Kit Components:
21075R/Y kits:
1 - 21275R/Y lamp
1 - 94862 plug
21051R/Y & 21080R/Y kits:
1 - 21251R/Y or 21880R/Y lamp
1 - 94862 plug
21056R/Y kits:
1 - 21256R/Y lamp
1 - 94862 plug
Recommended Accessories:
• 97034 mounting gasket
• 97036 sealing gasket
• Plugs: Pages 225-228
FMVSS:
• P2,PC
• Reflectorized - A,P2
• Available with standard or reflectorized lens
• PC rated lamps have 8 diode pattern
• Reflex lamps have 1 diode (red) & 2 diode
(yellow) pattern
See Page 2
LED PC Rated Kits
21075R Red
21075Y Yellow
LED PC Rated Lamps
21275R Red
21275Y Yellow
LED P2 Hardwired
Lamps w/Reflex
21253Y Yellow
LED P2 Kits w/Reflex
21051R Red
21051Y Yellow
21080R Red, diamond shell
21080Y Yellow, diamond shell
21056R Red, 24v
21056Y Yellow, 24v
LED P2 Lamps w/Reflex
21251R Red
21251Y Yellow
21880R Red, diamond shell
21880Y Yellow, diamond shell
21256R Red, 24v
21256Y Yellow, 24v
2.0"
6.0"
• Reflectorized lens on colored lens versions
• Optional mounting & sealing gaskets available to improve seal
between lamps and body of vehicle
• Less susceptible to shock & vibration
2150
Red lamp
2150A Yellow lamp
LED
Marker &
Clearance
Sealed 8 Diode Pattern
Material:
• Acrylic lens & housing
• 16 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 13.5v, 0.12 amp
Recommended Accessories:
• 97034 mounting gasket
FMVSS:
• Reflectorized - A,P2
• P2
2150A
2152
2152A
2150
2152 Red lamp w/clear non-reflectorized lens
2152A Yellow lamp w/clear non-reflectorized lens
