100 / 348
BACK-UP LAMPS
LIC
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
98
2.15
5.50
2.11
4.31
See page 97
40
®
Series Back-Up
Sealed
Material:
• Polycarbonate lens & housing
• ABS flange
Light Source:
• Designed at 12.8v, 2.1 amp, 32 cp
Kit components:
40004 grommet kit:
1 - 40204 12v lamp
1 - 40700 grommet
1 - 94992 plug
40012 grommet kit:
1 - 40212 24v lamp
1 - 40700 grommet
1 - 94992 plug
40024 flange kit:
1 - 40224 lamp & gray flange
1 - 94992 plug
FMVSS:
• R
• Polycarbonate lens & housing are vibration sealed
• Bulb is shock mounted for extended life
• Legal only for back-up function for 1 or 2 lamp
systems
• Not recommended for dome lamp use
• Replaces Signal-Stat 4041W & 4047W
40204 or 40212
40224
40004
Clear grommet kit
40012
Clear grommet kit, 24v
40024
Clear gray flange kit
40071 Clear black flange kit
40204
Clear lamp
40212
Clear lamp, 24v
40206C Clear lamp w/clear back
40224
Clear lamp & gray flange
40262
Clear lamp & black flange
4.300
2.003
Male Pin Back-Up
Sealed
Material:
• Polycarbonate lens & housing
Light Source:
• Designed at 12.8v, 2.1 amp, 32 cp
Recommended Accessories:
• Mounting: Pages 259-261
FMVSS:
• R(2)
• Features male pin connections
• High impact polycarbonate lens & housing
• Shock mount resists road shock &
vibration
• Two lamps required to meet federal lighting
regulations
• Not recommended for dome lamp use
• Replaces Grote® #62211
49203C Clear lamp
5.424
.430
2.510
See page 97
40
®
Series Back-Up
Bulb Replaceable
Material:
• Polycarbonate lens & housing
Light Source:
• Bulb: One #1156
Kit Components:
40306 kit:
1 - 99010C lens/housing
1 - 40700 grommet
1 - 94937 socket assembly
Replacement Parts:
• 99010C clear lens/housing
• 40700 grommet
• 94937 socket assembly
Recommended Accessories:
• Mounting: Pages 259-261
FMVSS:
• R
• Polycarbonate lens & housing are sonically
welded
• Socket assembly cams-in for quick & easy
bulb replacement
• Legal as back-up lamp only
• Not recommended for dome lamp use
40306
Clear grommet kit
