BACK-UP LAMPS
LIC
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
96
1.620
5.380
See page 97
80
®
Series Back-Up
Bulb Replaceable
Material:
• Steel housing
• Polycarbonate lens
• Hardwired
Light Source:
• Bulb: #1156, 32 cp
Replacement Parts:
• 99008C lens
• 97945 retaining ring
• 97093 mounting gasket
• 97094 lens gasket
FMVSS:
• R(2)
• Features flush mount housing with recessed lens
• Snap-in retaining ring holds lens in place
• Requires two lamps to meet Federal
• Lighting Regulations
• Replaces Signal-Stat 4111W
80342
Clear lamp w/black housing
80344
Clear lamp w/stainless steel housing
80345
Clear lamp w/polished stainless
steel housing
0.20 screw hole diameter
5.00 bolt hole circle
4.43 diameter mounting hole
5.25
2.00
4.87
1.33
4.25
See page 97
Flush Back-Up
Bulb Replaceable
Material:
• Zinc die cast housing
• Polycarbonate lens
• Hardwired
Light Source:
• Bulb: #1156, 32 cp
Replacement Parts:
• 9016W lens
• 9021W lens kit
• 9102 plug
FMVSS:
• R(2)
3693W
• Three screw polycarbonate lens security
• Narrow depth fits in trucks & vans with
limited access
• Zinc die cast housing
3693W Clear lamp w/chrome housing
2.09
5.50
2.11
4.31
See page 95
Super 40
®
Back-Up
Sealed
Material:
• Polycarbonate or acrylic lens
& housing
Light Source:
• Designed at 13.5v, 2.1 A
, 32 cp
Kit Components:
40044 grommet kit:
1 - 40244 lamp
1 - 40700 grommet
1 - 94992 plug
Recommended Accessories:
• Mounting: Pages 259-261
• Plugs: Pages 213-216
FMVSS:
• R(2)
• Uniquely designed shock mount extends lamp life
• Sealed polycarbonate lens & housing resist heat &
impact
• Flange & flush mount grommets designed for
mounting in a 4-1/2” hole
• Not recommended for dome lamp use
• Two lamps required to meet Federal Lighting
Regulations
• Uses standard PL-2 connection
Super 40 Lamp
40244 Clear
Super 40 Lamp & Flange
40260
Clear, black flange
40261
Clear, gray flange
Super 40 Grommet Kit
40044 Clear
