BACK-UP LAMPS
LIC
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
97
4060C
4063C
1.64
5.50
4.32
1.57
LED
Super 44
®
Back-Up
Sealed
6 Diode Pattern
Material:
• Polycarbonate lens, housing & flange
• 16 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 12.5v, 0.53 amp
Recommended Accessories:
• Mounting: Pages 259-261
• Plugs: Pages 213-216
FMVSS:
• R
• Features robust, cost effective, efficient design
• Surpasses back-up specifications with 1 lamp, eliminating 2 lamp systems
• 6 diode pattern creates a uniform look when mounted with S44 products
• Epoxy encapsulated with exclusive Fit ‘N Forget® plug assembly, keeps
corrosives away from lamp
• Not recommended for dome lamp use
• U.S. Registered TM #3483147
Super 44 Lamp & Flange
44344C Clear, gray flange
44991C Clear, gray flange, diamond shell
44346C Clear, black flange
44992C Clear, black flange, diamond shell
44348C Clear, black flange, hardwired blunt cut
44345C Clear, white flange
44349C Clear, white flange, hardwired blunt cut
Super 44 Lamp
44350C Clear
44990C Clear, diamond shell
44347C Clear, Hardwired w/
PL3 connector
Flange Kits
44181C Kit, gray flange
44182C Kit, black
flange, diamond shell
Grommet Kits
44180C Clear
44184C Clear, diamond shell
4.4"
1.75"
LED
Back-Up
Sealed
24 Diode Pattern
Material:
• Polycarbonate lens & housing
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 13.5v, 0.249 amp
Recommended Accessories:
• Mounting: Pages 259-261
• Plugs: Pages 213-216
FMVSS:
• R(2)
• Uses standard right angle PL-2 connection
• Unique LED array retails full pattern light output design
• Epoxy encapsulated electronics
• Two lamps required for back-up
4060C Clear lamp
4063C Clear lamp, integral flange
5.46”
4.94”
0.25”
See Page 2
