CAMSHAFTS
BRAKE CAMSHAFTS — TRAILER AXLE
DEXTER 12-1/4” TRAILER BRAKES 28 SPLINE 1-1/2” JOURNAL DIA.
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
B
CAMSHAFT
REPAIR KIT
BRAKE
REPAIR KIT
GENERAL INFORMATION
E-10917
LH
1-1/16”
Dexter 034-188-01
16-3/8” 2-7/32”
E-2469
E-10875
E-10918
RH
Dexter 034-189-01
E-10919
LH
1-1/16”
Dexter 034-188-04
20-5/16” 2-7/32”
E-10920
RH
Dexter 034-189-04
E-10921
LH
1-1/16”
Dexter 034-188-00
21-1/8” 2-7/32”
E-10922
RH
Dexter 034-189-00
E-10923
LH
1-1/16”
Dexter 034-188-03
22-5/16” 2-7/32”
E-10924
RH
Dexter 034-189-03
E-10925
LH
1-1/16”
Dexter 034-188-05
23-3/8” 2-7/32”
E-10926
RH
Dexter 034-189-05
E-10927
LH
1-1/16”
Dexter 034-188-11
24-5/8” 2-7/32”
E-10928
RH
Dexter 034-189-11
E-10929
LH
1-1/16”
Dexter 034-188-09
26-1/2” 2-7/32”
E-10930
RH
Dexter 034-189-09
Extended service camshafts CAN be used in place of standard camshafts.
Standard camshafts CANNOT be used in place of extended service camshafts when sing Extended service shoes and/or linings.
All Euclid Cam Lengths are measured from under Cam Head to beginning of Lock Ring Groove.
