CAMSHAFTS
BRAKE CAMSHAFTS — TRAILER AXLE
HENDRICKSON INTRAAX - 10 SPLINE
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
B
C
CAMSHAFT
REPAIR KIT
BRAKE
REPAIR KIT GENERAL INFORMATION
E-11864
LH
1-1/8”
Hendrickson S-23857-1L
11-1/32” 2-5/16” 8-11/16”
E-11450HD
(exposed)
E-11897
(enclosed)
E-2769HD
Can be used with
Enclosed Cam Tube
or Exposed Cam 2”
O.D. bushing and
seal.
E-11865
RH
Hendrickson S-23857-1R
HENDRICKSON INTRAAX - 28 SPLINE
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
B
C
CAMSHAFT
REPAIR KIT
BRAKE
REPAIR KIT GENERAL INFORMATION
E-10899
LH
1-3/8”
Hendrickson S-20806-1L
11-1/32” 2-5/16”
E-9791HD
(exposed
1-7/8” O.D.)
E-11450HD
(exposed 2”
O.D.)
E-11897
(enclosed)
E-2769HD
Standard Series.
E-10900
RH
Hendrickson S-20806-1R
E-11866
LH
1-1/8”
Hendrickson S-24636-1L
11-1/32” 2-5/16” 8-11/16”
E-2769HD
HXS. Can be used with
Enclosed Cam Tube or
Exposed Cam 2” O.D.
bushing and seal.
E-11867
RH
Hendrickson S-24636-1R
All Euclid Cam Lengths are measured from under Cam Head to beginning of Lock Ring Groove.
