CAMSHAFTS
BRAKE CAMSHAFTS — TRAILER AXLE
1-1/2” DIAMETER MULTI-APPLICATION CAMSHAFTS FOR TRAILERS WITH 16-1/2” BRAKE - Double Groove
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
B
C
CAMSHAFT
REPAIR KIT
GENERAL INFORMATION
E-557
LH
1-3/8”
Dana/Spicer M16WK103-17
Meritor 2210P6412
Std. Forge 202100-205L
20-3/8” 2-7/32” 1-5/8”
E-20889
Eaton (Bolt-on)
E-2123
Easton
(Weld-on)
E-2088AHD
Meritor
E-2287 Spicer &
Std. Forge
Premium Universal. Entire
camshaft is heat treated for
maximum bearing life and
twist resistance.
E-556
RH
Dana/Spicer M16WK102-17
Meritor 2210N6410
Std. Forge 202100-205R
E-2107
LH
1-3/8”
Eaton 820073
Meritor R607022
20-3/8” 2-5/16” 1-5/8”
Original Eaton Style Large S
Head. Roller seats completely
into S Head
E-2108
RH
Eaton 820074
Meritor R607021
E-1425A
LH
1-3/8”
Meritor R607082
20-7/16” 2-3/16” 1-5/8”
For Q Plus brakes. Standard
Universal 1-5/8” Groove
used on Paymaster RN and
RL Axles
E-1424A
RH
Meritor R607081
E-691
LH
1-3/8”
Dana/Spicer 17-599 Eaton
B-1691-9 Meritor R607052
Std. Forge 202100-225L
22-1/16” 2-9/16” 2-7/32”
E-690
RH
Dana/Spicer 17-598 Eaton
B-1691-10 Meritor R607051
Std. Forge 202100-225R
E-1095
LH
1-3/8”
Dana/Spicer M16WK103-25 Eaton
7-2426 Meritor R607002 Std. Forge
202100-236L
23-7/16” 2-5/16” 2-7/32”
Extra long for use with Air
Ride Suspensions Extra
length keeps slack adjuster
from rubbing on air bags and
causing premature rupture
E-1094
RH
Dana/Spicer M16WK102-25 Eaton
7-2425 Meritor R607001 Std. Forge
202100-236R
All Euclid Cam Lengths are measured from under Cam Head to beginning of Lock Ring Groove.
