CAMSHAFTS
BRAKE CAMSHAFTS — TRAILER AXLE
1-1/2” DIAMETER MULTI-APPLICATION CAMSHAFTS FOR TRAILERS WITH 16-1/2” BRAKES - Single Groove
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
B
CAMSHAFT
REPAIR KIT
GENERAL INFORMATION
E-4892
LH
1-3/8”
Dana/Spicer 17-611
7-13/32” 2-7/32”
E-20889
Eaton
(Bolt-on)
E-2123
Easton
(Weld-on)
E-2088AHD
Meritor
E-2287
Spicer & Std.
Forge
E-4893
RH
Dana/Spicer 17-610
E-1789
LH
1-3/8”
Eaton 820102 Meritor R607018
10-1/8” 2-7/32”
For Eaton Self-Contained Trailer
Brakes
E-1788
RH
Eaton 820103 Meritor R607017
E-4713
LH
1-3/8”
Dana/Spicer M16WK102-7 Meritor R607040
16-5/16” 2-7/32”
For use on Granning
Suspensions
E-4712
RH
Dana/Spicer M16WK103-7 Meritor R607039
E-687
LH
1-3/8”
Dana/Spicer 17-577, M16WK103-9
Eaton 7-2402, B-1691-47,
Meritor 2210Y6317 Std. Forge
202100-166L
16-1/2” 2-7/32”
Used on Meritor R-100 Axles
Also used on Ford, GMC,
WhiteGMC, Diamond T Tag or
Pusher Axles
E-686
RH
Dana/Spicer17-576, M16WK102-9
Eaton 7-2401, B-1691-48
Meritor2210X6316 Std. Forge
202100-166R
E-2795
LH
1-3/8”
Dana/Spicer 17-569, M16WK117
Meritor R607032 Std. Forge
202100-175L
17-3/8” 2-7/32”
E-2794
RH
Dana/Spicer 17-568, M16WK116 Meritor
R607031 Std. Forge 202100-175R
E-4715
LH
1-3/8”
17-3/4” 2-7/32”
E-4714
RH
E-689
LH
1-3/8”
Dana/Spicer 17-579, M16WK103-12
Eaton 72404, B1691-5 Std. Forge 202100-
185L
18-3/8”
2-7/32”
E-688
RH
Dana/Spicer 17-578, M16WK102-12,
Eaton 72403, B1691-6 Std. Forge 202100-
185R
18-3/8”
All Euclid Cam Lengths are measured from under Cam Head to beginning of Lock Ring Groove.
