CAMSHAFTS
BRAKE CAMSHAFTS — TRAILER AXLE
FOR SPICER (STD. FORGE) TRAILER AXLES WITH 12-1/4” BRAKES
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
B
C
CAMSHAFT
REPAIR KIT
BRAKE
REPAIR KIT
GENERAL INFORMATION
E-9743
LH
1-1/16”
Dana/Spicer M12WK101-11
Dana/Spicer M12WK107-1
Std. Forge 202103191L
18-7/8” 2-7/32” 2-21/32”
E-2469
(Nylon
spider
bushing)
E-5307
(Bronze
spider
bushing)
Check
Application
Spicer (Dana) and Std.
Forge 12-1/4” x 5-1/2”
and 12-1/4” x 7-1/2”
Brakes.
Also can be used for Dexter
12-1/4” Brakes.
E-9744
RH
Dana/Spicer M12WK100-11
Dana/Spicer M12WK106-1
Std. Forge 202103191R
E-5096
LH
1-1/16”
Dana/Spicer M12WK107-3
Std. Forge 202103-206L
20-1/2” 2-7/32” 2-21/32”
E-5097
RH
Dana/Spicer M12WK106-3
Std. Forge 202103-206R
E-1411
LH
1-1/16”
Dana/Spicer M12WK107-6
Std. Forge 202103-213L
Std. Forge UB-22-64L
21-1/8” 2-7/32” 2-21/32”
E-1410
RH
Dana/Spicer M12WK106-6
Std. Forge 202103-213R
Std. Forge UB-22-64R
E-9745
LH
1-1/16”
Dana/Spicer M12WK107-7
Std. Forge 202103222L
22” 2-7/32” 2-21/32”
E-9746
RH
Dana/Spicer M12WK100-16
Std. Forge 202103222R
E-1423
LH
1-1/16”
Dana/Spicer 17-691
Std. Forge 202103-233L
Std. Forge UB-24-15L
23-1/4” 2-7/32” 2-21/32”
E-1422
RH
Dana/Spicer M12WK100-17
Std. Forge 202103-233R
Std. Forge UB-24-15R
E-1421
LH
1-1/16”
Dana/Spicer M12WK101-19
Std. Forge 202103-241L
Std. Forge UB-22-23L
23-7/8” 2-7/32” 2-21/32”
E-1420
RH
Std. Forge 202103-241R
Std. Forge UB-22-23R
E-2793
LH
1-1/16”
Dana/Spicer M12WK101-18
Std. Forge 202103-247L
24-5/8” 2-7/32” 2-21/32”
E-2792
RH
Dana/Spicer M12WK100-18
Std. Forge 202103-247R
E-9747
LH
1-1/16”
Dana/Spicer M12WK101-22
Dana/Spicer M12WK107-13
26-1/2” 2-7/32” 2-21/32”
E-9748
RH
Dana/Spicer M12WK100-22
Dana/Spicer M12WK106-13
All Euclid Cam Lengths are measured from under Cam Head to beginning of Lock Ring Groove.
