Assembly PN
Description
Drum PN
3.34
4.65
6.85
11.25
6 Holes 5/16"-18 UNC,
5.50 Bolt Circle
0.50
6.50
SAE "N" Spindle
Inner Bearing Cup / Cone
Outer Bearing Cup / Cone
Ductile Iron 10 stud hub w/ 11.25" Dia. Bolt Circle. Uses Inboard Drum - Shoulder Stud
Hub Specifications
A: Hub Overall Length
B: Inner Cup to Mounting Face
C: Distance Between Cups
D: Tone Ring Bore Diameter
E: Tone Ring Bore Depth
J: Bolt Circle
K: Bolt Pattern
L
Brake
Face Dia
P
Brake
Face Width
I
Hub Pilot
N
Overall
Depth
G - Stud PN M - Cup
to Drum
Thread Stud Stand
Out
O
Cup Face
to Mtg.
Assy
Weight
Drum
1006 Series Assemblies
HM218210 / HM218248
HM212011 / HM212049
Std. Hub Weight
53 lbs.
001-10061
Stud Pilot, 3/4-16 RH Stud, 16.5 x 7" Drum
52020-01
16.50 7.63
9.44
9.50
3/4-16 RH
1.35
6.89
152
3.50
PRT-00874
RH
001-10062
Stud Pilot, 3/4-16 LH Stud, 16.5 x 7" Drum
52020-01
16.50 7.63
9.44
9.50
3/4-16 LH
1.35
6.89
152
3.50
PRT-00875
LH
Option "T" - ABS Tone Ring
6.77
PRT-13237
100-Tooth Tone Ring - Powdered Metal
Part Number
Description
Pitch Diameter
Notes
Uses PRT-00152 Locknut.
