MOUNTING
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
255
ACC
30410
5.031
3.229
2.400
• High impact plastic deflector mount
• Inner bracket cams-on, cams-off lamp for
quick installation
• Outer bracket provides additional protection
• Designed for use with lamp #30200R/Y or
#30250R/Y
• Not recommended for PC requirements
• Black epoxy painted heavy steel
• Use for mounting Model 30 grommets
• Replaces Signal-Stat 9397
Deflector Mount
For 2” Lamps
Material:
• Polycarbonate mount
• PVC grommet
• 16 gauge wire
Kit Components:
30405 mount kit:
1 - 30722 mount
1 - 30701 grommet
1 - 94902 plug
Deflector Mount
For 2” Lamps
Material:
• ABS mount
Kit Components:
30410 mount kit:
1 - 30730 inner mount
1 - 30731 outer mount
3.00
4.81
4.00
1.75
2.31dia.
0.375 bolt hole diameter
Mounting Bracket
For 2” Lamps
Material:
• Heavy gauge steel
• High impact plastic deflector mount
• Allows quick & easy surface mounting of 2” diameter lamps
• Meets PC requirements on a 45˚ angle using standardcombination lamps
• Not recommended for LED applications
• Replaces Signal-Stat 9388
30504R
30405
4.00
2.34
1.00
4.80
0.203 screw hole diameter
30410 Mount, kit
30730 Inner mount
30731 Outer mount
30728
Bracket
30504R Red lamp kit
30504Y Yellow lamp kit
30405
Gray mount kit
30722
Gray
