CAMSHAFTS
BRAKE CAMSHAFTS — TRAILER AXLE
1-1/2” DIAMETER MULTI-APPLICATION CAMSHAFTS FOR TRAILERS WITH 16-1/2” BRAKES - Single Groove
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
B
CAMSHAFT
REPAIR KIT
GENERAL INFORMATION
E-2413
LH
1-3/8”
Dana/Spicer 17579, M16WK111-4,
Eaton 72406, B1691-45, Std. Forge 202100-
187L
18-5/8”
2-7/32”
E-20889
Eaton
(Bolt-on)
E-2123
Easton
(Weld-on)
E-2088AHD
Meritor
E-2287 Spicer
& Std. Forge
1/4” longer than E-688 and
E-689. Can be used for both
applications
E-2412
RH
Dana/Spicer 17578, M16WK110-4,
Eaton 72405, B1691-46, Std. Forge 202100-
187R
E-685
LH
1-3/8”
Dana/Spicer M16WK103-19, Eaton 7-2418,
Meritor 2210A6319, Std. Forge 202100-213L
21-3/32” 2-7/32”
E-684
RH
Dana/Spicer M16WK102-19, Eaton 7-2417,
Meritor 2210Z6318, Std. Forge 202100-213R
E-9089
LH
1-3/8”
Dana/Spicer 17-585, Meritor 2210J2948,
Std. Forge 202100-225L
22-3/8” 2-7/32”
E-9090
RH
Dana/Spicer 17-584, Meritor 2210H2946,
Std. Forge 202100-225R
E-4884
LH
1-3/8”
Dana/Spicer 17-595, Dana/Spicer
M16WK102-23, Meritor R607056
22-7/8” 2-7/32”
E-4885
RH
Dana/Spicer 17-594, Dana/Spicer
M16WK103-23, Meritor R607055
E-4717
LH
1-3/8”
Dana/Spicer 17-587, M16WK102-26,
Eaton 7-2426, 820084, Meritor 2210D6400,
Std. Forge 202100-242L
24” 2-7/32”
E-4716
RH
Dana/Spicer 17-586, M16WK103-26,
Eaton 7-2425, 820083, Meritor 2210C6399,
Std. Forge 202100-242R
E-2797
LH
1-3/8”
Dana/Spicer M16WK102-83, M16WK111-12,
Eaton 7-2432, Meritor R607034, Std. Forge
202100-245L
24-3/8” 2-7/32”
For Std. Forge Axles on End
Dump Trailers
E-2796
RH
Dana/Spicer M16WK103-83, M16WK110-12,
Eaton 7-2431, Meritor R607033, Std. Forge
202100-245R
E-4719
LH
1-3/8”
Dana/Spicer M16WK102-88, Eaton 820087,
Meritor R607044
25-3/4” 2-7/32”
Extra long for use on Air Ride
Suspensions
E-4718
RH
Dana/Spicer M16WK103-88, Eaton 820088,
Meritor R607043
All Euclid Cam Lengths are measured from under Cam Head to beginning of Lock Ring Groove.
