CAMSHAFTS
BRAKE CAMSHAFTS — TRAILER AXLE
FOR MERITOR TRAILER AXLES WITH 16-1/2” Q PLUS BRAKES
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
B
CAMSHAFT
REPAIR KIT
BRAKE
REPAIR KIT
GENERAL INFORMATION
E-5507
RH
1-3/16”
Meritor 2210B6866
17-5/16” 1-31/32”
E-9078HD
(Press-in spider
bushings)
E-9079HD
(Bolt-on spider
bushings)
E-2769HD
Can be used with cast or
fabricated spiders and all
spider bushings. E-9075
Washer must be used when
using these camshafts with
nylon or metal press-in spider
bushings.
These cams are “extended life”
versions of this manufacturer’s
“standard version”. If
retrofitting from “standard”
to “extended life” camshafts,
Euclid strongly recommends
replacing both cams on a
single axle or all cams on
tandem axles to promote a
balanced brake condition.
E-5506
LH
Meritor 2210C6867
E-5508
LH
1-3/16”
Meritor 2210G6871
20-13/32” 1-31/32”
E-5509
RH
Meritor 2210F6870
E-5510
LH
1-3/16”
Meritor 2210E6869
24-1/16” 1-31/32”
E-5511
RH
Meritor 2210D6868
FOR MERITOR TRAILER AXLES WITH 16-1/2” BRAKES
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
B
C
CAMSHAFT
REPAIR KIT
BRAKE
REPAIR KIT
GENERAL INFORMATION
E-14822
LH
1-3/16”
Meritor 2210B6866
17-5/16” 1-31/32” 1-63/64”
E-3520A
E-3520AHD
E-3989AHD
E-9078HD
E-9079HD
Double snap ring groove
under head.
E-14823
RH
Meritor 2210C6867
E-14824
LH
1-3/16”
Meritor 2210G6871
20-13/32” 1-31/32” 1-63/64”
E-14825
RH
Meritor 2210F6870
E-14820
LH
1-3/16”
Meritor 2210E6869
24-1/16” 1-31/32” 1-63/64”
E-14821
RH
Meritor 2210D6868
All Euclid Cam Lengths are measured from under Cam Head to beginning of Lock Ring Groove.
