Assembly Part Number Index
Assembly Part Number Index by Gunite Hub PN
Assembly PN Assembly Description
Hub Casting Description
SAE
Code
Inner Cup
Inner Cone
Outer Cup
Outer Cone
Catalog
Page
006-02133L Hub Pilot, M22 x 4.82 Stud, 16.5 x 8-5/8” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
K30
752
759
742
740
39
006-02134
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
K30
752
759
742
740
40
006-02134L Hub Pilot, M22 x 4.82” Stud, 16.5 x 7” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
K30
752
759
742
740
40
006-02135
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
K30
752
759
742
740
39
006-02135L Hub Pilot, M22 x 4.82 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
K30
752
759
742
740
39
006-02136
Stud Pilot, 3/4-16 RH Stud, 16.5 x 7” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
K30
752
759
742
740
40
006-02137
Stud Pilot, 3/4-16 LH Stud, 16.5 x 7” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
K30
752
759
742
740
40
006-02138
Hub Pilot, M22 x 3.97 Stud, 16.5 x 8-5/8” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
K30
752
759
742
740
40
006-02138L Hub Pilot, M22 x 4.82” Stud, 16.5 x 8-5/8” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
K30
752
759
742
740
40
007-09518
Hub Pilot M24 x 5.47 Stud, 18 x 7” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
W
(A45)
772
787
6535
6580
41
011-04000L
Hub Pilot M18 x 3.15 Stud, 12.80 x 4” Drum Bal
Ductile Iron 6 stud hub w/ 8.07” Dia Bolt Circle. Uses Outboard
Drum - Clipped Head Stud
I80
(FC)
JM207010
JM207049A
25820
25877
42
011-04100
Hub Pilot M22 x 2.87 Studs, 15” Rotor
Ductile Iron 8 stud hub w/ 275mm Dia. Bolt Circle. Uses Rotor -
Serrated stud
I80
(FC)
JM207010
JM207049A
25820
25877
43
012-05010L Hub Pilot M18 x 1.5 Stud, 12.8” 4.35” Drum Bal
Ductile Iron 6 stud hub w/ 205.05mm Dia. Bolt Circle, Uses Out-
board Drum - Serrated stud
N/A
39520
39581
3820
3877
44
012-05110L
Hub Pilot M22 x 1.5 Stud, 12.8” x 4” Drum Bal
Ductile Iron 8-stud hub w/ 275mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
N/A
39520
39581
3820
3877
45
014-09442
Hub Pilot M24 x 5.47 Stud, 18 x 7” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
A65
892
896
6535
6580
46
Gunite PN
KIC PN
Description
SAE
Designation
Catalog Page
5712-4
001-00125 Hub Pilot, M22 x 3.94 Stud, 16.5 x 7” Drum
N
20
5711-4
001-00125L Hub Pilot, M22 x 4.79 Stud, 16.5 x 7” Drum
N
20
5714RH3
001-00126 Stud Pilot, 3/4-16 RH Stud, 16.5 x 7” Drum
N
20
5714LH3
001-00127 Stud Pilot, 3/4-16 LH Stud, 16.5 x 7” Drum
N
20
5716-3
001-00136 Hub Pilot, M22 x 3.94 Stud, 16.5 x 7” Drum
N
23
5715-3
001-00136L Hub Pilot, M22 x 4.79 Stud, 16.5 x 7” Drum
N
23
HF850K
001-02540L Hub Pilot, M22 x 3.94 Stud, 16.5 x 6” Drum Bal
N
24
HF850K
001-02545L Hub Pilot, M22 x 3.94 Stud, 16.5 x 5” Drum Bal
N
24
