Assembly Part Number Index
Assembly PN Assembly Description
Hub Casting Description
SAE
Code
Inner Cup
Inner Cone
Outer Cup
Outer Cone
Catalog
Page
004-00130L Hub Pilot, M22 x 4.82 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
33
004-00131
Stud Pilot, 3/4-16 RH Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
33
004-00132
Stud Pilot, 3/4-16 LH Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
33
004-01043
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
35
004-01043L Hub Pilot, M22 x 4.82 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
35
004-01048
Hub Pilot, M22 x 3.97 Stud, 16.5 x 8 5/8” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
35
004-01048L Hub Pilot, M22 x 4.82 Stud, 16.5 x 8 5/8” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
35
004-21043
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
35
004-21043L Hub Pilot, M22 x 4.82 Stud, 16.5 x 7” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
35
004-40103
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
31
004-40103L Hub Pilot, M22 x 4.82 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
31
004-40110
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
32
004-40110L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
32
004-40310
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
34
004-40310L Hub Pilot, M22 x 4.82 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
34
004-41045
Hub Pilot, M22 x 3.97 Stud, 12.25 x 7.5” Drum
Ductile Iron 8-stud hub w/ 275mm Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
36
004-41045L Hub Pilot, M22 x 4.82 Stud, 12.25 x 7.5” Drum
Ductile Iron 8-stud hub w/ 275mm Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
36
005-51005L Hub Pilot, M22 x 4.25 Stud, 16.5 x 6” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FL
6420
6461A
552A
555S
38
005-51005X Hub Pilot, M22 x 4.82 Stud, 16.5 x 6” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FL
6420
6461A
552A
555S
38
006-02133
Hub Pilot, M22 x 3.97 Stud, 16.5 x 8-5/8” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
K30
752
759
742
740
39
