Assembly Part Number Index by Webb Hub PN
Webb PN
KIC PN
Description
SAE
Designation
Catalog Page
10069BETL
001-10062 Stud Pilot, 3/4-16 LH Stud, 16.5 x 7” Drum
N
18
10069BETR
001-10061 Stud Pilot, 3/4-16 RH Stud, 16.5 x 7” Drum
N
18
10519CLML
001-10512 Stud Pilot, 3/4-16 LH 12.25” x 7.5” Drum
N
19
10519CLMR
001-10511 Stud Pilot, 3/4-16 RH 12.25” x 7.5” Drum
N
19
20231UQ3
001-00125 Hub Pilot, M22 x 3.94 Stud, 16.5 x 7” Drum
N
20
20231UQ5
001-00125L Hub Pilot, M22 x 4.79 Stud, 16.5 x 7” Drum
N
20
20231UQML
001-00127 Stud Pilot, 3/4-16 LH Stud, 16.5 x 7” Drum
N
20
20231UQMR
001-00126 Stud Pilot, 3/4-16 RH Stud, 16.5 x 7” Drum
N
20
20241GRML
001-00086 JIS, 285mm B.C., M20 X 1.5 LH 16.5 x 7”
N
17
20241GTMR
001-00085 JIS, 285mm B.C., M20 X 1.5 RH 16.5 x 7”
N
17
20271CW3
001-00133 Hub Pilot, M22 x 3.94 Stud, 12.25 x 7.5” Drum
N
22
20271CW5
001-00133L Hub Pilot, M22 x 4.79 Stud, 12.25 x 7.5” Drum
N
22
20281UF3
001-00136 Hub Pilot, M22 x 3.94 Stud, 16.5 x 7” Drum
N
23
20281UF5
001-00136L Hub Pilot, M22 x 4.79 Stud, 16.5 x 7” Drum
N
23
20331FJ3
001-00103 Hub Pilot, M22 x 3.94 Stud, 16.5 x 7” Drum
N
16
20331FJ5
001-00103L Hub Pilot, M22 x 4.79 Stud, 16.5 x 7” Drum
N
16
20331FJML
001-00078 Stud Pilot, BSF LH Stud, 16.5 x 7” Drum
N
16
20331FJMR
001-00077 Stud Pilot, BSF RH Stud, 16.5 x 7” Drum
N
16
22501XQ
011-04100 Hub Pilot M22 x 2.87 Studs, 15” Rotor
I80 (FC)
46
23231UQ3
004-00130 Hub Pilot, M22 x 3.94 Stud, 16.5 x 7” Drum
P
34
23231UQ5
004-00130L Hub Pilot, M22 x 4.79 Stud, 16.5 x 7” Drum
P
34
23231UQML
004-00132 Stud Pilot, 3/4-16 LH Stud, 16.5 x 7” Drum
P
34
23231UQMR
004-00131 Stud Pilot, 3/4-16 RH Stud, 16.5 x 7” Drum
P
34
23431JA5
004-00148L Hub Pilot, M22 x 4.79 Stud, 16.5 x 8-5/8” Drum
P
35
23431UQ3
004-00143 Hub Pilot, M22 x 3.94 Stud, 16.5 x 7” Drum
P
35
23431UQ5
004-00143L Hub Pilot, M22 x 4.79 Stud, 16.5 x 7” Drum
P
35
24011UH4
006-02134 Hub Pilot, M22 x 3.94 Stud, 16.5 x 7” Drum
K30
40
24311FJ3
006-02135 Hub Pilot, M22 x 3.94 Stud, 16.5 x 7” Drum
K30
39
24331FK3
006-02133 Hub Pilot, M22 x 3.94 Stud, 16.5 x 8-5/8” Drum
K30
39
25201RX1
002-00137 Hub Pilot, M22 x 3.70 Stud, 15 x 4” Drum Bal
FF/FG
29
25301KV3
005-01005L Hub Pilot, M22 x 4.25 Stud, 16.5 x 6” Drum Bal
FL
38
25401KN3
001-02545L Hub Pilot, M22 x 3.94 Stud, 16.5 x 5” Drum Bal
N
24
25401KV3
001-02540L Hub Pilot, M22 x 3.94 Stud, 16.5 x 6” Drum Bal
N
24
25401RK3
001-02547L Hub Pilot, M22 x 3.94 Stud, 16.5 x 7” Drum Bal
N
24
70159CKH
001-70003 3-Spoke x 15” Wheel, 12.25 x 7.5” Drum
N
25
75209GCH
001-75207 5-Spoke x 20” 16.5 x 7” Brake Drum
N
26
76209GCH
001-76207 6-Spoke x 20” 16.5 x 7” Brake Drum
N
27
76229GCH
001-76227 6-Spoke x 22” 16.5 x 7” Brake Drum
N
28
Assembly Part Number Index by Gunite Hub PN
Gunite PN
KIC PN
Description
SAE
Designation
Catalog Page
5721-2
004-00130 Hub Pilot, M22 x 3.94 Stud, 16.5 x 7” Drum
P
34
5719RH2
004-00131 Stud Pilot, 3/4-16 RH Stud, 16.5 x 7” Drum
P
34
5719LH2
004-00132 Stud Pilot, 3/4-16 LH Stud, 16.5 x 7” Drum
P
34
5720-2
004-00143L Hub Pilot, M22 x 4.79 Stud, 16.5 x 7” Drum
P
35
HF805K
005-01005L Hub Pilot, M22 x 4.25 Stud, 16.5 x 6” Drum Bal
FL
38
