Assembly Part Number Index
Assembly PN Assembly Description
Hub Casting Description
SAE
Code
Inner Cup
Inner Cone
Outer Cup
Outer Cone
Catalog
Page
001-10061
Stud Pilot, 3/4-16 RH Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Inboard
Drum - Shoulder Stud
N HM218210
HM218248
HM212011
HM212049
17
001-10062
Stud Pilot, 3/4-16 LH Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Inboard
Drum - Shoulder Stud
N HM218210
HM218248
HM212011
HM212049
17
001-10511
Stud Pilot, 3/4-16 RH 12.25” x 7.5” Drum
Ductile Iron 10 stud hub w/ 8.75” Dia. Bolt Circle. Uses Inboard
Drum - Shoulder Stud
N HM218210
HM218248
HM212011
HM212049
20
001-10512
Stud Pilot, 3/4-16 LH 12.25” x 7.5” Drum
Ductile Iron 10 stud hub w/ 8.75” Dia. Bolt Circle. Uses Inboard
Drum - Shoulder Stud
N HM218210
HM218248
HM212011
HM212049
20
001-21025
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” Drum Bal
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-21025L Hub Pilot, M22 x 4.82 Stud, 16.5 x 7” Drum Bal
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-70003
3-Spoke x 15” Wheel, 12.25 x 7.5” Drum
Ductile Iron 3-spoke 15”
N HM218210
HM218248
HM212011
HM212049
23
001-75000
5-Spoke x 20” 16.5 x 7” Brake Drum
Ductile Iron 5-spoke 20”
N HM218210
HM218248
HM212011
HM212049
24
001-75207
5-Spoke x 20” 16.5 x 7” Brake Drum
Ductile Iron 5-spoke 20”
N HM218210
HM218248
HM212011
HM212049
25
001-76227
6-Spoke x 22” 16.5 x 7” Brake Drum
Ductile Iron 6-spoke 22”
N HM218210
HM218248
HM212011
HM212049
26
002-00137
Hub Pilot, M22 x 3.70 Stud, 15 x 4” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
27
002-00137L Hub Pilot, M22 x 3.97 Stud, 15 x 4” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
27
002-00138
Stud Pilot, 3/4-16 RH Stud, 15 x 4” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
27
002-00139
Stud Pilot, 3/4-16 LH Stud, 15 x 4” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
27
002-00142
Hub Pilot, M22 x 3.70 Stud, 16.5 x 5” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
27
002-00142L Hub Pilot, M22 x 3.97 Stud, 16.5 x 5” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
27
002-00144
Hub Pilot, M22 x 3.70 Stud, 15 x 5” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
27
002-00144L Hub Pilot, M22 x 3.97 Stud, 15 x 5” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
27
002-00200
Hub Pilot, M22 x 3.70 Stud, 15 x 4” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
30
002-00200L Hub Pilot, M22 x 3.97 Stud, 15 x 4” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
30
004-00130
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
33
