17 / 105
16
Copyright © 2015 KIC LLC
Assembly PN
Description
Drum PN
3.35
4.87
7.06
335mm (13.19")
6 Holes 5/16"-18 UNC,
5.50 Bolt Circle
0.44
6.50
SAE "N" Spindle
Inner Bearing Cup / Cone
Outer Bearing Cup / Cone
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard Drum - Serrated stud
Hub Specifications
A: Hub Overall Length
B: Inner Cup to Mounting Face
C: Distance Between Cups
D: Tone Ring Bore Diameter
E: Tone Ring Bore Depth
J: Bolt Circle
K: Bolt Pattern
L
Brake
Face Dia
P
Brake
Face Width
I
Hub Pilot
N
Overall
Depth
G - Stud PN M - Cup
to Drum
Thread Stud Stand
Out
O
Cup Face
to Mtg.
Assy
Weight
Drum
1002 Series Assemblies
HM218210 / HM218248
HM212011 / HM212049
Std. Hub Weight
59 lbs.
001-00103
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7" Drum
54250-01
16.50 7.44
11.25 10.59
M22 x 1.5
2.65
9.81
177
0.78
PRT-00117
001-00103L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 7" Drum
54250-01
16.50 7.44
11.25 10.59
M22 x 1.5
3.50
9.81
179
0.78
PRT-00118
001-00104
Hub Pilot, M22 x 3.70 Stud, 16.5 x 7" Drum
54250-01
16.50 7.44
11.25 10.59
M22 x 1.5
2.41
9.81
177
0.78
PRT-00121
Option "T" - ABS Tone Ring
6.77
PRT-13237
100-Tooth Tone Ring - Powdered Metal
Part Number
Description
Pitch Diameter
