MOUNTING
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
248
ACC
• High impact plastic deflector mount
• 33® series bracket mounting holes retrofit Model
19 bracket installations
• Suitable for PC requirements on 45˚ angle when
using 33 series PC rated/ combination lamp
• 33711 allows lamp to be surface mounted &
wiring routed outside vehicle
Note: 33 series grommet or flange is required to
install lamp in bracket
• Designed to mount on 4.6” radius corner
• Screws mount perpendicular to radius
• Allows lamp to be surface mounted using 33®
series grommet or flange
• Suitable for PC requirements
Note: 33 series grommet or flange is required
to install lamp in bracket
33711
Deflector Mounts
For 33
®
Series
Products
Material:
• White polycarbonate
plastic
• Grey ABS plastic
4.21"
1.92"
1.80"
Curved Deflector
Mount
For 33
®
Series
Products
Material:
• Grey ABS plastic
1.09”
grommet mount
• Flush mounts 3/4” diameter lamps
to vehicle
• Chrome plated flange improves the
appearance on vehicle
• Snap fit grommet and flange, no
screws required
Grommet &
Flange Mounts
For 33
®
Series
Lamps
Material:
• EPDM Grommet
• Nylon Flange
• Chrome Plated Flange
1.16”
.75”
flange mount
0.75 mounting hole
33720
33725
33702
33712 Branch deflector, gray
33711 Surface mounted deflector
33715 Bracket
33700 Grommet, black
33702 Grommet, black, closed back
33800 Flange, black
33810 Flange, chrome
33705 License grommet, black
33720 Grommet, (0.070-0.125)
33725 Grommet, (0.125-0.250)
