MOUNTING
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
254
ACC
30403
3.90"
3.50"
1.00"
2.15"
1.93"
0.218 screw hole diameter
4.500
5.375
2.750
.875
0.250 screw hole diameter
4.000
4.380
1.25
2.340
0.203 screw hole diameter
30404
30727
30701
Adapter Mounts
For 2” Lamps
Material:
• Polycarbonate mount
• PVC grommet
Deflector Mounts
For 2” Lamps
Material:
• Polycarbonate mount
• PVC grommet
• 16 gauge wire
Kit Components:
30404 mount kit:
1 - 30721 mount
1 - 30700 grommet
1 - 94902 plug
• High impact plastic mount
• Design allows surface mounting
of 2” diameter lamps
• Not recommended for PC
requirements or LED applications
• High impact plastic mount
• Quick cam-on, cam-off lamp installation
• Suitable for PC requirements on a 45˚
angle using LED or incandescent
PC rated/combination lamps
• Not recommended for use with
Signal-Stat LED lamps
Cam-On Mounts
For 2” Lamps
Material:
• Polycarbonate mount
• 16 gauge wire
Kit Components:
30403 mount kit:
1 - 00801 mount
1 - 94902 plug
• High impact plastic mount
• Design allows surface mounting
of 2” diameter lamps
• Meets PC requirements on a 45˚
angle using LED or incandescent
PC rated/combination lamps
• Replaces Signal-Stat 9395
30727
Mount
30701
Grommet
30403 Mount, kit
00801 Mount
30404
Mount, kit
30721
Gray mount
30729
Black mount
