MOUNTING
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
251
ACC
10414
10410
3.000
4.000
1.070
2.200
0.220 screw hole diameter
Surface Mounts
For 2-1/2” Lamps
Material:
• Aluminum mount
• PVC grommet
• 16 gauge wire
Kit Components:
10412 mount kit:
1 - 10722 mount
1 - 10700 open back grommet
1 - 94902 plug
1 - 97907 wire grommet
10413 mount kit:
1 - 10722 mount
1 - 10702 closed back grommet
1 - 94902 plug
1 - 97907 wire grommet
Cam-On Mounts
For 2 & 2-1/2” Lamps
Material:
• Polycarbonate mount
• 16 gauge wire
Kit Components:
10410 mount kit:
1 - 10728 gray mount
1 - 94924 side entry plug
Branch Deflector
Mounts
For 2-1/2” Lamps
Material:
• Polycarbonate mount
• PVC grommet
• 16 gauge wire
Kit Components:
10414 mount kit:
1 - 10725 mount
1 - 10700 grommet
1 - 94902 plug
3.875
3.250
1.000
0.195 screw hole diameter
• Design allows surface mounting of 2-1/2”
lamps in a grommet
• Suitable for PC requirements on a
45˚ angle when using LED or incandescent
PC rated/combination lamps
• High impact plastic mount
• Branch deflector cams-on 2 & 2-1/2” lamps
• Requires 94924 sideentry plug
• Suitable for PC requirements on a 45˚ angle
when using LED or incandescent PC rated/
combination lamps
• Not recommended for use with
Signal-Stat LED products• Replaces Signal-Stat 9390
• High impact plastic deflector mount
• Design allows surface mounting of
2-1/2” lamps
• Suitable for PC requirements on a 45˚ angle
when using LED or incandescent PC rated/
combination lamps
10412
4.750
3.12
.968
5.75
10412 Open back mount, kit
10413 Closed back mount, kit
10722 Mount
10410 Gray mount, kit
10721 Clear mount w/o ribs
10724 Gray mount w/o ribs
10727 Clear mount 8-1/2” radius
10728 Gray mount
10520Y Yellow lamp kit
10414 Gray mount kit
10725 Gray mount
10731 Black mount
