TURN SIGNAL LAMPS
SIG
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
40
LED
Round Front/
Park/Turn w/Integral
Flange
Material:
• Polycarbonate lens & housing
Light Source:
• LED, 24 diodes
• 12 V @ 0.01A - 0.138 A
FMVSS:
• FMVSS P2; FMVSS S2;
FMVSS I6; FMVSS T
LED
Round, 10 Diode
Front/Park/Turn
Material:
• Acrylic lens & housing
Light Source:
• LED, 10 diodes
• 12 V @ 0.02A - 0.12 A
FMVSS:
• FMVSS P2; FMVSS I6; FMVSS
S2 (3); FMVSS T
• Housing and flange are molded together to form one piece
• Uses standard right angle PL-3 connection
• Designed with impact-resistant polycarbonate material
• LEDs do not have a filament, therefore are not susceptible to shock and vibration
damage major cause of failure for lamps with an incandescent bulb
• Epoxy encapsulated electronics prevents damage from moisture and corrosion
• When properly mounted, exceeds FMVSS DOT requirements for S/T/T and F/P/T
• Lamps come with Truck-Lite 2-Year Limited Warranty
• Engineered to feature ten bright and economical light emitting diodes (LEDs)
• Uses standard PL-3 connector
• When properly mounted, exceeds FMVSS-P2 DOT requirements for marker/clearance performance
• Designed with impact-resistant acrylic material
• Sealed lens and housing locks moisture out
• Snap fit grommet requires no screws for installation
• LEDs do not have a filament, therefore are not susceptible to shock and vibration damage major cause
of failure for lamps with an incandescent bulb
• Epoxy encapsulated electronics prevents damage from moisture and corrosion
• Popular on owner/operator and show trucks
• Lamps come with Truck-Lite 2-Year Limited Warranty
4053A Integral flange, lamp, yellow
4058A Lamp, yellow
5.46”
4.94”
0.25”
4.4"
1.75"
