TURN SIGNAL LAMPS

6.53

3.34

1.75

Series Turn Signal

Bulb Replaceable

Material:

• Polycarbonate lens & housing

• PVC grommet

• 16 gauge wire

Light Source:

• Bulb #3157 wedge

• Designed at 12v, 2.1 amps, 32 cp

Kit Components:

60344R/Y grommet kits:

1 - 99184R/Y lens & housing

1 - 60700 grommet

1 - 95415 socket assembly

Replacement Parts:

• 99184R red lens/housing

• 99184Y yellow lens/housing

Recommended Accessories:

• Mounting: Pages 262-263

FMVSS:

• I6

• Uses standard mounting

holes &accessories

60344R Red, kit

60344Y Yellow, kit

LED

60 Series

Side Turn

Signal & Marker Lamp

Materials

• Polycarbonate Lens and Housing

Light Source

• 6 Diodes

• Signal Function: 0.6A @ 13.5V

• Marker Function: 0.035A @ 13.5V

SAE Codes

• P2 Rated

• E and E2 Rated

Connectors

• Hard-Wired .180 Bullet, Hard-

Wired Blunt Cut, and Fit N Forget

plugs, .180 terminals available

Terminals Available

Recommended Accessories

• 60700: Grommet (Fits 60421Y &

60422Y)

• Complies with SAE J2039 standards; a requirement by California Title 13 law

• Available in integral flange, grommet, and surface mount

• Engineered to withstand the toughest working environments on earth

• Commonly mounted at “mid-point” on trailers or “no zone” areas on tractors

• Sealed design locks moisture out

• LEDs have no filament, therefore are not susceptible to shock & vibration, a

major cause of failure for lamps with incandescent bulbs

• Less current draw, resulting in increased battery & alternator life while

allowing more power for other vehicle requirements

• Backed by our industry-leading Lifetime Warranty

60420Y Integral flange, Fit N Forget, lamp, yellow

60421Y Grommet mount, Fit N Forget, lamp, yellow

60422Y Grommet mount, hard-wired, blunt-cut

60424Y / 60425Y

60421Y / 60422Y

60420Y / 60423Y

7.87"

3.31"

7.24"

Integral Flange

6.5"

2.32"

Grommet Mount

5.42"

2.69"

4.81"

Surface Mount

60423Y Integral flange, hard-wired, blunt-cut

60424Y Surface mount, hard-wired, .180 bullet

60425Y Surface mount, hard-wired, blunt-cut
