43 / 348
SIG
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
41
TURN SIGNAL LAMPS
LED
Oval Front/Park/
Turn w/Integral Flange
Material:
• Polycarbonate housing &
acrylic lens
Light Source:
• LED, 24 diodes
• 12 V @ 0.02A - 0.26 A
FMVSS:
• FMVSS P2; FMVSS I6;
FMVSS S2 (3); FMVSS T
LED
10 Diode, Oval
Front/Park/Turn Lights
Material:
• Acrylic housing & lens
Light Source:
• LED, 10 diodes
• 12 V @ 0.02A - 0.172 A
FMVSS:
• FMVSS P2; FMVSS I6;
FMVSSS2 (3); FMVSS T
• Housing and flange are molded together to form one piece
• Uses standard right angle PL-3 connection
• Designed with impact-resistant polycarbonate material
• LEDs do not have a filament, therefore are not susceptible to shock and vibration
damage major cause of failure for lamps with an incandescent bulb
• Epoxy encapsulated electronics prevents damage from moisture and corrosion
• When properly mounted, exceeds FMVSS DOT requirements for S/T/T and F/P/T
• Lamps come with Truck-Lite 2-Year Limited Warranty
• Engineered to feature ten bright and economical light emitting diodes (LEDs)
• When properly mounted, exceeds FMVSS-P2 DOT requirements for marker/clearance performance
• Designed with impact-resistant acrylic material
• Sealed lens and housing locks moisture out
• Snap fit grommet requires no screws for installation
• LEDs do not have a filament, therefore are not susceptible to shock and vibration damage major cause of failure for
lamps with an incandescent bulb
• Epoxy encapsulated electronics prevents damage from moisture and corrosion
• Popular on owner/operator and show trucks
• Lamps come with Truck-Lite 2-Year Limited Warranty
6053A Integral flange, lamp, yellow
6058A Lamp, yellow
7.24”
7.56”
3.31”
0.20”
0.24”
1.75"
6.5"
2.25"
