PEDESTAL LAMPS
SIG
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
46
Single Face
Pedestal Lamp
Bulb Replaceable
Material:
• Acrylic lens
• Polycarbonate housing
• 16 gauge wire
Light Source:
• Designed at 12v,
2.1 amp, 32 cp
• Bulb: #1156 T/S
• Bulb: #1157 S/T/T
Replacement Parts:
• 8936 red lens
• 8936A yellow lens
• 9102 T/S plug
FMVSS:
• One wire: I6
• Two wire: S2,T
4.27"
.5"–20
1.0"
2.0"
4.66"
1/2 – 20
4.125
2.00
0.875
4.625
See Page 44
See Page 44
Single Face
Pedestal Lamp
Bulb Replaceable
Material:
• Acrylic lens
• Zinc die cast housing
• 16 gauge wire
Light Source:
• Bulb: #1157 S/T/T
Replacement Parts:
• 9016 red lens
• 9016A yellow lens
• 9016W clear lens
• 9016B blue lens
• 9016G green lens
FMVSS:
• I,S,T
2702
• For vehicle application with
vehicle width under 80” wide
2702 Red, black housing
2702A Yellow, black housing
Single Face
Pedestal Lamp
Bulb Replaceable
Material:
• Polycarbonate lens
• Zinc die cast housing
• 16 gauge wire
Light Source:
• Bulb: #1157 S/T/T
Replacement Parts:
• 9341 red lens
• 9341A yellow lens
FMVSS:
• I6,S2,T
• Rubber O-ring seals
out dirt & moisture
• Snap-on lens for easy
bulb replacement
3762 Red, gray housing
3756
3753A
2.00
4.38
1/2 – 20
1.00
5.00
• Snap-on lens simplifies
bulb and lens replacement
3753D Red, white housing, one wire, retail pack
3754D Red, white housing, two wire, retail pack
3755D Red, black housing, one wire, retail pack
3756D Red, black housing, two wire, retail pack
3753AD Yellow, white housing, one wire, retail pack
3755A Yellow, black housing, one wire
4.125
2.00
1/2 – 20
4.625
.875
See Page 44
Single Face
Pedestal Lamp
Bulb Replaceable
Material:
• Acrylic lens
• Zinc die cast housing
• 16 gauge wire
Light Source:
• Bulb: #1156
Replacement Parts:
• 9016 red lens
• 9021 red lens kit
• 9016A yellow lens
• 9021A yellow lens kit
• 9016W clear lens
• 9021W clear lens kits
• 9016B blue lens
• 9016G green lens
• 9102 pigtail
FMVSS:
• I
• For vehicle application
with vehicle width under
80” wide
2701 Red, black housing
2701A Yellow, black housing
3701 Red, gray housing
