TURN SIGNAL LAMPS
SIG
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
42
LED
10 Diode
Turn Signal Lights
Material:
• Polycarbonate housing &
acrylic lens
Light Source:
• LED, 10 diodes
• 12 V @ 0.03A - 0.28 A
FMVSS:
• FMVSS P2; FMVSS S2;
FMVSS I6; FMVSS T
• Uses standard right angle
PL-3 connection
• 10-24 diode pattern
• Unique LED array displays
full pattern light output
• Epoxy encapsulated
electronics
4558A Lamp, yellow
3.4”
5.3”
1.9”
LED
Side Turn, .180
Bullet, Red
Material:
• Polycarbonate lens & housing
Light Source:
• LED, 6 diodes
• 12 V @ 0.03A - 0.29 A
SAE Codes
• P2 Rated
• E and E2 Rated
60424R Lamp, red
5.38
2.30
Turn Signal
Bulb Replaceable
Material:
• Polycarbonate lens
• Steel housing
• 18 gauge wire
• Stainless steel ring
Light Source:
• Bulb #1156, S-8 bayonet
• Designed at 12.8v, 2.1 amp, 32 cp
Replacement Parts:
• 99008R red lens
• 99008Y yellow lens
• 97945 retaining ring
• 97093 mounting gasket
• 97094 lens gasket
FMVSS:
• I6
• Flush mount lamp with recessed lens
81300Y Yellow, black steel
Combination Side Marker
& Side Turn Signal
Bulb Replaceable
Material:
• Polycarbonate lens & housing
• Rubber gasket
• 16 gauge wire
Light Source:
• Bulb: #3157
Recommended Accessories:
• 9289 mounting bracket
FMVSS:
• P2,PC
4.81
6.00
2.00
2.00
• Red for supplemental stop light or turn signal,
yellow for side turn signal and marker lamp
• For Navistar #1677711C91 replacement use
Signal Stat # 4091A w/9468
4091 Red lamp
4091A Yellow lamp
4094 Red lamp w/9463 harness
4094A Yellow lamp w/9463 harness
4094A
