45 / 348
SIG
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
43
TURN SIGNAL LAMPS
Combination Side
Marker & Side
Turn Signal
Sealed
Material:
• Polycarbonate lens &
housing
• Rubber gasket
• 16 gauge wire
Light Source:
• Bulb: #3157
FMVSS:
• P2,PC
4.81
6.00
2.00
2.00
• Red for supplementary stop light or turn signal
• Yellow for side turn signal and marker lamp
4095A
9463 HARNESS
4093 Red lamp
4093A Yellow lamp
4095 Red lamp w/9463 harness
4095A Yellow lamp w/9463 harness
3.120
2.590
3.800
1.610
Turn Signal
Bulb Replaceable
Material:
• Polycarbonate lens & housing
• 18 gauge wire
Light Source:
• Bulb: T-4 cartridge
• Designed at 13.5v, 1.55 amp,
20 cp
Replacement Parts:
• 80604 bulb
FMVSS:
• E
• Sequential: P2
20309Y Yellow lamp
20310Y Yellow lamp w/ground wire
• Features snap-in lens with a 90˚ maximum
edge visibility
20309Y
3.12
2.63
3.81
1.49
2.87
1.44
Turn Signal
Bulb Replaceable
Material:
• Polycarbonate lens & housing
• 16 gauge wire
Light Source:
• 20301Y - Bulb #1156, S-8
bayonet 12v bulb designed at
2.1 amp, 32 cp
• 20304Y & 20316Y - Bulb
#1157, S-8 DC 12v bulb
designed at 2.1/.59 amp,
32/3 cp
FMVSS:
• E,I
20301Y
• Features side turn function, with two versions also
meeting marker requirements
20301Y Yellow lamp
20304Y Yellow lamp w/clear mkr.
20316Y Yellow lamp w/clear mkr. & .180 molded bullet
.250 screw hole
diameter
