CAMSHAFTS
BRAKE CAMSHAFTS — TRAILER AXLE
FOR MERITOR TRAILER AXLES WITH 12-1/4” BRAKES
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
B
CAMSHAFT
REPAIR KIT
BRAKE
REPAIR KIT
GENERAL INFORMATION
E-4900
LH
11/16”
Meritor 2210G6169
20-3/8” 1-23/32”
E-3520A
E3520AHD
E3989AHD
E-3484
E-4901
RH
Meritor 2210H6170
FOR MERITOR TRAILER AXLES WITH 12-1/4” BRAKES
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
B
CAMSHAFT
REPAIR KIT
BRAKE REPAIR
KIT
GENERAL INFORMATION
E-3516
LH
11/16”
Meritor 2210T5246
20-3/8” 1-23/32”
E-3520A
E3520AHD
E3989AHD
E-3484
E-3517
RH
Meritor 2210D6166
E-9087
LH
11/16”
Meritor 2210E6167
23-7/32” 1-23/32”
E-9088
RH
Meritor 2210F6168
FOR MERITOR TRAILER AXLES WITH 15” Q PLUS BRAKES
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
B
CAMSHAFT
REPAIR KIT
BRAKE REPAIR
KIT
GENERAL INFORMATION
E-11958
LH
1”
Meritor 2210B7958
23-3/8” 1-63/64”
Contact Florence Information
Services for Repair Kit details.
E-11959
RH
Meritor 2210C7959
All Euclid Cam Lengths are measured from under Cam Head to beginning of Lock Ring Groove.
