CAMSHAFTS
BRAKE CAMSHAFTS — TRAILER AXLE
FOR MERITOR 4000-6000 SERIES TRAILER AXLES WITH 16-1/2” BRAKES
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
B
CAMSHAFT
REPAIR KIT
BRAKE
REPAIR KIT
GENERAL INFORMATION
E-2447A
LH
1-3/16”
Meritor R607066
17-5/16” 1-45/64”
E-3520A
E-3520AHD
E-3989AHD
E-2769HD
E-2448A
RH
Meritor R607065
E-2449A
LH
1-3/16”
Meritor R607070
20-13/32” 1-45/64”
E-2450A
RH
Meritor R607069
E-2451A
LH
1-3/16”
Meritor R607068
24-1/16” 1-45/64”
E-2452A
RH
Meritor R607067
FOR MERITOR 4000-6000 SERIES TRAILER AXLES WITH 16-1/2” Q PLUS BRAKES
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
B
CAMSHAFT
REPAIR KIT
BRAKE
REPAIR KIT
GENERAL INFORMATION
E-2441B
LH
1-3/16”
Meritor 2210R8156
17-5/16” 1-45/64”
E-3520A
E-3520AHD
E-3989AHD
E-2769HD
Q Plus, Q and P brakes. Cast
spiders with press-in bushings.
Fabricated spiders with weld-on
bushings.
E-2442B
RH
Meritor 2210Q8155
E-2443B
LH
1-3/16”
Meritor 2210T8158
20-13/32” 1-45/64”
E-2444B
RH
Meritor 2210S8157
E-2445B
LH
1-3/16”
Meritor 2210V8160
24-1/16” 1-45/64”
E-2446B
RH
Meritor 2210U8159
All Euclid Cam Lengths are measured from under Cam Head to beginning of Lock Ring Groove.
